KERUI H.265 8Ch 5MP CCTV Security System

KERUI H.265 8Channel 5MP POE Camera Security System CCTV Kit  Camera IR-CUT Waterproof Video Surveillance Face Detection Camera.

Face record/ face detection/face playback

Record very face that appears on the Lens. without missing any details. face playback it is very easy to choose the video that you want to watch.

5 Megapixels High Definition

Full HD resolution and quality enhancing efficiency and monitoring capabilities.

IP66 Waterproof Camera

5.0MP Pixel Resolution,20 meters night vision use for outdoor.

Multiple alarm detection and notification methods

Support Face Detection, Motion Detection, Camera lens was covered Alarm detection method.
Support Buzzer, Email and APP push notification methods.

Connection Diagram

Power Over Ethernet, long transmission distance. POE Connection, Don’t need Power Supply.

With only a single ethernet cable connecting each IP camera to the NVR for both power and video transmission, PoE (Power over Ethernet) security system allows you to DIY the camera position anywhere you want. No need of a separate power adapter for power supply of each camera, truly freeing you from messy and tiring cablings

Easy access via mobile APP

Remote watch live video anytime anywhere, Support iPhone, Android mobile

5MP Camera Specification

Specifications :IVG–83X50PS- -S S

System : Embedded RTOS design, dual-core 32-bit DSP (XM550AI)

Image Sensor: 1/3” CMOS SENSOR

Video processing: H.265AI / H.265 + (compatible with H.265 / H.264) encoding, dual stream, AVI format; stream 0.1M ~ 8Mpbs adjustable; frame rate 1 ~ 30 frames / second

Image output Main stream: 5MP 2592 * 1944 @ 15fps; 4MP 2560 * 1440 @ 20fps;

Effective Pixel: 5MP 2592×1944

Camera Lens:3.8mm Lens

Number of IR LEDs:6pcs Array IR Leds

Power：powered by POE NVR

Waterproof Level:IP66 waterproof level

Camera Material: Metal and ABS Plastic. Metal waterproof effect will better.

Interface Port：RJ45 Network cable 10 / 100M self-adaptive; support RTSP / FTP / DHCP / NTP / UPnP and other network protocols (combined with power interface)

Reliability: Comprehensive lightning protection, in line with national international standards;
7 * 24 hours -10 ℃ ~ 65 ℃ test is stable and reliable (including complete machine test)

H.265 POE NVR Specification

Power Supply: DC 48V
Video Compression: H.265/H.264 All Support
Video Outputs: HDMI / VGA
Hard Drive (HDD): 1*SATA port (support up to 6TB)
Record mode: continuous/time schedule/face Detection/P2P Remote View
P2P Remote View: Support iOS, Android
support RTSP / FTP / DHCP / NTP / UPnP and other network protocols (combined with power interface)
20+ Languages Available: Russian, English, Italian, Portuguese, Spanish, French, German etc
